$490.00Original price was: $490.00.$390.00Current price is: $390.00.
About this item
Establishes a direct point-to-point conversion between automotive ECU’s using 1000BASE-T1/BroadR-Reach(1000 Mbit/s Fullduplex,) and any standard Fast Ethernet (1000 Mbit/s, 1000BASE-TX) device with an standard ethernet RJ45 connector.
Comes with 1x Unshielded Twisted Pair (UTP) cable and 1x 12V power adapter.
By using the Broadcom BroadR-Reach PHY BCM89881B1BFBG, ensure a trustworthy and effective tool to customers that are looking for a cost-efficient, quick and manageable solution for testing requirements, with no latency and no packet loss.
Features with 1000BASE-T1 Master / Slave configuration and link LED.
Plug and Play, No need to install the drivers. 100M and 1000M modes can be switched manually.
$399.00Original price was: $399.00.$219.00Current price is: $219.00.
About this item
Establishes a direct point-to-point conversion between automotive ECU’s using 1000BASE-T1(1000 Mbit/s Fullduplex,) and any standard Fast Ethernet (1000 Mbit/s, 1000BASE-TX) device with an standard ethernet RJ45 connector. Only supports 1000BASE communication, not compatible with 100BASE.
By using the AEC-Q100 qualified TI DP83TG720SWRHATQ1 IEEE 802.3bp and Open Alliance compliant automotive Ethernet physical layer transceiver, ensure a trustworthy and effective tool to customers that are looking for a cost-efficient, quick and manageable solution for testing requirements, with no latency and no packet loss.
Comes with 1x TE MATEnet and 1x MOLEX adapter. Do not provide the over unshielded twisted pair (UTP) cables.
Features with 1000BASE-T1 Master / Slave configuration and an OLED screen. Support Cable open and short fault detection.
Plug and Play, No need to install the drivers.Data pass-through is conducted without disrupting any network protocols.
$310.00Original price was: $310.00.$210.00Current price is: $210.00.
Features:
Establishes a direct point-to-point conversion between automotive ECU’s using 100BASE-T1/BroadR-Reach(100 Mbit/s Fullduplex,) and any standard Fast Ethernet (100 Mbit/s, 100BASE-TX) device with an standard ethernet RJ45 connector.
Comes with 1x Unshielded Twisted Pair (UTP) cable and 1x 12V power adapter.
By using the BCM BroadR-Reach PHY BCM89811B1AWMLG, ensure a trustworthy and effective tool to customers that are looking for a cost-efficient, quick and manageable solution for testing requirements, with no latency and no packet loss.
Features with 100BASE-T1 Master / Slave configuration and link LED.
100BASE Ethernet Media Converter establishes a direct point-to-point conversion between automotive ECU’s using 100BASE-T1(100 Mbit/s Fullduplex,) and any standard Fast Ethernet (100 Mbit/s, 100BASE-TX) device with an standard ethernet RJ45 connector.
100BASE Ethernet Media Converter comes with 1x TE MATEnet and 1x MOLEX adapter. Do not provide the over unshielded twisted pair (UTP) cables. No extra hardware or software is needed to connect the device with a PC or a Laptop.
By using the NXP TJA1101 IEEE 802.3bw compliant ethernet PHY transceiver, ensure a trustworthy and effective tool to customers that are looking for a cost-efficient, quick and manageable solution for testing requirements, with no latency and no packet loss.
Features with 100BASE-T1 Master/Slave configuration and link LED. The design makes it portable and easy to install in test racks. The galvanized sheet steel with black powder coating housing makes it robust.
Plug and Play, No need to install the drivers. No customized driver is needed to interact with our 100BASE-T1-TX-N Media Converter. The device communicates with standard Ethernet through an RJ-45 connector.
$1,900.00Original price was: $1,900.00.$1,500.00Current price is: $1,500.00.
About this item
10G/5G/2.5GBASE-T1 to 10G/5G/2.5G/1G/100M BASE-T (RJ45/SFP+) Full Duplex Conversion. point-to-point data transmission, with no delay, no data packet modification, and no data storage. Base on the Broadcom BroadR-Reach PHY bcm89890.
Plug and Play, No need to install the drivers. TI port Support for Speed Fixed and Speed Auto-Negotiation Mode configuration
By using the DIP switch, you can easily set the Speed mode of T1, the master/slave operation mode, and the Auto Negotiation mode.
Features with Speed and link state indicator LED.
A custom-made SFP+ to RJ45 module transceiver is included with the shipment. Please do not use other commercially available SFP+ to RJ45 modules with this setup.
The USB to CAN Converter Cable compatible with all series Raspberry Pi/Jetson Nano/Tinker Board/any single board computer, desktop and laptop.
The USB CAN Cable support Windows System, Mac OS and Linux, Raspbian(v5.4 kernel), Ubuntu.
Plug and Play USB CAN device. No external power required. Support wider CAN baud rate, from 20Kbps to 1Mbps can be programmed arbitrarily. Support for CAN bus 2.0A and 2.0B specification.
Provides 3000V voltage isolation and 2500V ESD isolated protection on signal pins.120 Ohm resistor selectable jumper feature.
Provide C/Python and source code with Socket-CAN for Raspbian(Linux), Dynamic library and demo with IOUSBKit for Mac Os(Big Sur).
The USB to CAN Converter Module compatible with all series Raspberry Pi/Jetson Nano/Tinker Board/any single board computer, desktop and laptop.
The USB CAN Module support Windows System, Mac OS and Linux, Raspbian(v5.4 kernel), Ubuntu.
Plug and Play USB CAN device. No external power required. Support wider CAN baud rate, from 20Kbps to 1Mbps can be programmed arbitrarily. Support for CAN bus 2.0A and 2.0B specification.
Provides 3000V voltage isolation and 2500V ESD isolated protection on signal pins.120 Ohm resistor selectable jumper feature.
Provide C/Python and source code with Socket-CAN for Raspbian(Linux), Dynamic library and demo with IOUSBKit for Mac Os(Big Sur).
