Description
Description:
- High cost performance camera, You no longer need pay high costs for your lightweight camera application. The video output support up to 720P x 30fps video output, could fulfill many video applications.
- U20CAM-720P is a native driver camera devices on most system, Windows11/10/7, Linux, Mac Os and other derived systems. Based on the UVC standard, so it could be supported by many ready-made camera application.
- Support hot plug into the USB port of your computer, notebook, Raspberry Pi ,Jetson nano and all single board computer. Plug and play device, no additional power supply and driver installation requirement.
- Features with 32*32mm compact sizes and on-Board 4 screw holes, it’s very easy to be installed in various occasions and be hidden.
Features:
- [High Compatibility] Native driver on Windows 11/10/7, Mac OS, Linux, Ubuntu and Android system. Raspberry Pi, Jetson Nano, Notebook, Desktop and Tablet PC
- [Superior Performer] Up to 720P*30 fps. Support YUY2 and MJPEG format.
- [Plug and Play USB Device] USB 2.0 High-speed and UVC standard device.
- [Wide Angle] Fov(D) = 120 degrees and Fov(H) = 102 degree.
- [Stable and Flexible] 32*32 mm compact size,Easy to be installed in various occasions. You also could buy the matching metal stamping shell on our Amazon shop separately.
Specification:
Sensor | Size | 1/4 Inch |
Resolution | 1280*720 | |
Image Color | Colours | |
Shutter type | Rolling shuttere | |
Lens | F(N) /Aperture | 2.2 |
Focal Length | 2.79 | |
TV DISTORTION | <-17% | |
CRA | 14 Degree | |
Lens Diameter | M12 | |
Lens Seat Spacing | 18mm | |
FOV-D | 120 Degree | |
FOV-H | 102 Degree | |
PCBA | Size | 32*32 mm |
Layers | 2 layers | |
Mounting Holes | 4 counts, Diameter 2.2mm |
|
Trigger | None | |
Strobe Flash | None | |
Night vision | Reserved | |
Interfaces | Communication Interface | USB Hgih-Speed |
Cable Length | 1 M | |
Software |
Communication Standard | UVC 1.0.0 |
Supported format | YUY2, MJPEG | |
Supported Frame rate | 30 fps | |
Supported Resolution | MJPES Output resolutions:
YUY2 Output resolutions:
|
|
Auto Parameters | White Balance(Manual Option) Exposure(Manual Option) |
|
Controllable Parameters | Brightness,Contrast,Hue,Saturation,Sharpness,Gamma,White Balance,Backlight Comp,Gain,Exposure,PowerLine Frequency,Low Light Compensation | |
Support System | Windows , Linux , Mac Os, Android | |
