U20CAM-IMX335 is a 5MP resolution camera module with STARVIS IMX335 CMOS sensor, image quality is very high and stable.
Features like a dynamic range up to 72 dB, advanced HDR functions and digital overlap HDR further improve the image quality and contrast behavior allowing for more detailed image analysis.
These features when combined with the low dark current performance and no smear further improve its performance in applications looking at both bright and dark regions at once.
The current module size is 32MM*32MM after your testing, we can adjust module size & shape according to your need, it will require some engineering cost. Compatible with Raspberry Pi ,Jetson Nano,PC Computers, Windows Linux Android Mac OS with UVC Driver.
5MP resolution with IMX335 CMOS sensor, STARVIS technology with high sensitivity performance, HDR (high dynamic range) function improves image quality and contrast behavior Excellent low illumination feature
Excellent image quality, Low power consumption
Plug And Play: UVC-compliant, support Windows, Linux, Mac OS and Android device with UVC, just connect the camera to PC, laptop or Raspberry Pi with the USB cable without extra drivers to be installed.
2MP resolution with OmniVision OV2719 CMOS sensor,Full HD 1080P resolution & 30fps frame rate, High quality image
UVC compliant, Plug & Play,Support Linux, Android, Mac and Windows,Module size is 32MM*32MM Widely used for Face recognition, AI, Computer vision, Robotics, Machine vision, imaging
Plug&Play: UVC-compliant, support Windows, Linux, Mac OS and Andriod device with UVC, just connect the camera to PC, laptop or Raspberry Pi with the USB cable without extra drivers to be installed.
U20CAM-PS5268 is 2MP resolution with PS5268 sensor, which features high sensitivity of 5800 mV/Lux-sec and wigh dynamic range (wDR) of 85dB, and can be used for all kinds of lighting conditions.
Our camera module size is 32mmx32mm and can be customized as per your requirement;
Also, A wide range of different lenses are available, with focal length from 2.8mm to 12mm, with view angle from
This camera module is widely used for many applications like security, surveillance, CCTV, industrial automation, automotive, factory automation, monitoring, access control, artificial intelligence (AI), machine vision, robotics, robots, computer vision, agriculture, education, 3D, detection, vision system, imaging, etc
The USB to CAN Converter Cable compatible with all series Raspberry Pi/Jetson Nano/Tinker Board/any single board computer, desktop and laptop.
The USB CAN Cable support Windows System, Mac OS and Linux, Raspbian(v5.4 kernel), Ubuntu.
Plug and Play USB CAN device. No external power required. Support wider CAN baud rate, from 20Kbps to 1Mbps can be programmed arbitrarily. Support for CAN bus 2.0A and 2.0B specification.
Provides 3000V voltage isolation and 2500V ESD isolated protection on signal pins.120 Ohm resistor selectable jumper feature.
Provide C/Python and source code with Socket-CAN for Raspbian(Linux), Dynamic library and demo with IOUSBKit for Mac Os(Big Sur).
The USB to CAN Converter Module compatible with all series Raspberry Pi/Jetson Nano/Tinker Board/any single board computer, desktop and laptop.
The USB CAN Module support Windows System, Mac OS and Linux, Raspbian(v5.4 kernel), Ubuntu.
Plug and Play USB CAN device. No external power required. Support wider CAN baud rate, from 20Kbps to 1Mbps can be programmed arbitrarily. Support for CAN bus 2.0A and 2.0B specification.
Provides 3000V voltage isolation and 2500V ESD isolated protection on signal pins.120 Ohm resistor selectable jumper feature.
Provide C/Python and source code with Socket-CAN for Raspbian(Linux), Dynamic library and demo with IOUSBKit for Mac Os(Big Sur).
$49.99Original price was: $49.99.$39.99Current price is: $39.99.
Datasheet: https://github.com/INNO-MAKER/usb2can
Features:
The USB to CAN Converter Module compatible with all series Raspberry Pi/Jetson Nano/Tinker Board/any single board computer, desktop and laptop.
The USB CAN Module support Windows System, Mac OS and Linux, Raspbian(v5.4 kernel), Ubuntu.
Plug and Play USB CAN device. No external power required. Support wider CAN baud rate, from 20Kbps to 1Mbps can be programmed arbitrarily. Support for CAN bus 2.0A and 2.0B specification.
Provides 3000V voltage isolation and 2500V ESD isolated protection on signal pins.120 Ohm resistor selectable jumper feature.
Provide C/Python and source code with Socket-CAN for Raspbian(Linux), Dynamic library and demo with IOUSBKit for Mac Os(Big Sur).
The Dual Channels Usb to Can Device compatible with all series Raspberry Pi/Jetson Nano/Tinker Board/any single board computer, desktop and laptop.
Support Windows System, Mac OS, Linux, Raspbian(v5.4 kernel) and Ubuntu.
Plug and Play USB CAN device. No external power required. CAN baud rate from 20Kbps to 1Mbps can be programmed arbitrarily. Support for CAN bus 2.0A and 2.0B specification.
Provides 3000VDC voltage isolation and 15kV Bus-Pin ESD protection.
Provide C/Python with Socket-CAN feature for Raspbian(Linux), C#/C++ demo for Windows, Dynamic library and demo with IOUSBKit for Mac Os(Big Sur).
